Price R6000-00

Intro

The Revelation-4 is the most powerful light system we build and it's also the brightest light you will find anywhere for this price. In our photo shoot we compared it to a 55watt H3 halogen spotlight and it doesn't take much to see the difference! [photos at bottom of page]

With its 5 power levels, the Revelation-4 is perfect for every type of night riding or racing you will do, whether it's a 24 hour solo, or a cross country night race.

We wanted to show off when we developed this light and that is exactly what you will do when waiting at the start line of your next race! Nothing we've seen compare to the Revelation-4!

Even the lowest level with a burn time of 50 hours on a 350g battery pack, is brighter than some LED lights of over R2000-00 in South Africa.

All parts in the Revelation-4 can be replaced, or upgraded when new technology becomes available.

Extra heavy-duty 5.3mm cable with O-ring sealed connectors connect the light unit to the battery.

The simple handlebar mount breaks away in the event of a severe crash to prevent damage to the light unit. It's easy to use, effective, and easy to replace in the event of a serious accident.

O-rings in the light body and cable connectors make the Revelation-3 fully waterproof.

Technical

Control :











MicroController that contains the user interface firmware

High efficiency boost mode switching regulator

Non-volatile EEPROM storage of operating modes (5 constant light levels, 5 strobe levels)

Input voltage sensing : low battery warnings and low voltage cutoff

Temperature sensing : light will dim to lower level when standing still or when 70degC is reached

Single switch to control light modes, strobe modes, on/off

LED's :
4 New generation high power LED's (16 watt) coupled to highly efficient optical reflectors

Light output :
85lm@level1 (50hrs), 440lm@level3 (8hrs), 980lm@level5 (2.5hrs) - 5431 LUX @ 2m (top brand 13 watt HID is 2114 LUX @ 2m)

System weight :
580g (light head + one battery pack in water bottle)

Battery pack/s :
2 battery packs incl. - each 44watt/h lithium polymer inside water bottle (350g)


Charger :



















MicroProcessor controlled balance charger (charges each cell in battery pack separately for optimum performance)

Detailed charging progress displayed on LCD (battery type, charge time, charge current, battery voltage, individual cell voltage, battery capacity)

Charges all types of rechargeable batteries (Pb, NiCD, NiMH, Li-Ion, Li-Po, Li-Fe)

Charge Revelation-4 battery in 3 hours

User inputs required (battery type, charging current, number of cells)

Included 4.5A 12v power supply for charger

How Bright is it?

Below are 5 photos resembling each power level of the Revelation-4 [click image for large version]

level 1 : 50 hours : 85lm

level 2 : 16 hours

level 3 : 8 hours : 440lm

level 4 : 4.5 hours

level 5 : 2.5 hours : 980lm


Revelation-4 vs 13 watt HID [click here]

Revelation-4 vs 55 watt Hella driving light [click here]

Revelation-4 level 1 (50 hours) vs X4 vs EVO X [click here]
